Bosch Magnetic Drill GBM 50-2
Technical Data
Rated power input: 1200 W
No-load speed: 50 – 250 / 510 rpm
Drill spindle connecting thread: MT 2 - DIN 228
Annular cutter: 50 mm
Max. twist drill: 23 mm
Max thread: M16
Max depth: 160 mm
Magnetic force: 14,000 N
Tools dimensions (W x L x H): 196 x 274 x 444 mm
Drilling dia. in steel: 1.5 / 50 mm
Weight : 14.7 kg (without cables and accessories)
Scope of Delivery
• 1 x Adapter for annular cutter (1 619 PB3 771)
• 1 x Hex key 3 mm (1 619 PB3 772)
• 1 x Hex key 4 mm (1 619 PB3 773)
• 1 x Hex key 6 mm (1 619 PB3 774)
• 1 x MT2 drill drift (1 619 PB3 776)
• 1 x Reduction sleeve (MT2/MT1) (1 619 PB3 777)
• 1 x Pilot pin (1 619 PB3 778)
• 1 x Safety strap (1 619 PB3 779)
• 1 x Coolant tank (1 619 PB3 763)
• 1 x Coolant tank holder (1 619 PB4 127)
• 1 x Carrying case (1 619 PB4 107)
• 1 x Crank handle (1 619 PB3 747)
